Computerized Flat Knitting Machine,computerized sweater knitting machine

Weihuan Machinery is a famous computerized flat knitting machine manufacturer and supplier in China, providing with computerized flat knitting machine free sample, welcome to buy discount products and wholesale good price and good quality products made in Yiwu, China from us and check the...

Send InquiryChat Now

Weihuan Machinery is a famous computerized flat knitting machine manufacturer and supplier in China, providing with computerized flat knitting machine free sample, welcome to buy discount products and wholesale good price and good quality products made in Yiwu, China from us and check the quotation with our factory.

1.Type WSG122-SC/SV
2.Gauge 3·5·7·9·10·12·14 3.5.7
3.Knitting widthVariably stoke, max 48/52/56/60/80/100
4. Knitting speed Knitting speed varies according to gauge and knitting condition, variably adjustable speed levels,10 additional programmable speeds max 1.4m/sec.
5. Stitch density60 section stitch selectable, adjustable scope supported by subdivision technology 0-350
6.Motor-driven racking mechanism max 2 inch racking,1/2 inch and 1/4 inch also available from any position. Low gauge use double rack, max 4 inch
7.Knitting systemDouble knitran system, due to the three-way-technique, it could knit ,tuck,miss knit in ocecam system
8. Knitting functionSimultaneous transfer, front or back, independent of carriage direction
9. Sinker systemCompound-type moveable full-sinker system
10.Needle selectionFull jacquard selection via special eight level solenoid actuators
11.Setup deviceTakedown comb with compound needles, it can catch and take off the fabric easily
12.Takedown deviceMain/sub rollers, changeable 31levels, automatically adjustable on each level, automatically opening and closing
13.Yarn cutterSingle-unit system includes 1 yarn cutter and 2 yarn grippers, left and right side standard
14.Yarn feed rollerLeft side standard, for especially suitable to knit yarns with low strength
Side tensions Side tension8 normal carriers


WH-F computerized flat knitting machine

SPECIFICATIONS

Type

WSG122-SC/SV

Gauge

3·5·7·9·10·12·14   3.5.7

Knitting width

Variably stoke, max 48/52/56/60/80/100

Knitting speed

Knitting speed varies according to gauge and knitting condition, variably adjustable speed levels,10 additional programmable speeds max 1.4m/sec.

Stitch density

60 section stitch selectable, adjustable scope supported by subdivision technology 0-350

Racking

Motor-driven racking mechanism max 2 inch racking,1/2 inch and 1/4 inch also available from any position. Low gauge use double rack, max 4 inch

Knitting system

Double knitran system, due to the three-way-technique, it could knit ,tuck,miss knit in ocecam system

Knitting function

Simultaneous transfer, front or back, independent of carriage direction

Sinker system

Compound-type moveable full-sinker system

Needle selection

Full jacquard selection via special eight level solenoid actuators

Setup device

Takedown comb with compound needles, it can catch and take off the fabric easily

Takedown device

Main/sub rollers, changeable 31levels, automatically adjustable on each level, automatically opening and closing

Yarn cutter

Single-unit system includes 1 yarn cutter and 2 yarn grippers, left and right side standard

Yarn feed roller

Left side standard, for especially suitable to knit yarns with low strength

Side tensions

Side tension  8 normal carriers

Yarn carriers

16 normal carriers

Top tensions

16 top tensions, one-touch easy threading, large knots cause machine stop

Stop motion

Yarn break, large knot, wraparound check, shock detection, piece count, over-torque, program error, etc

Drive system

Belt drive AC, servo motor,no lubrication necessary

Safety devices

Full safety cover for noise-suppression and dustproofing with stop motion sensor and interlock mechanism, stop button, power supply disconnection device, ultra-low speed “crawl” setting, CE mark, indicator lamps

Operation lamp

Green=normal operation, flashing green=normal stop, flashing amber=abnormal stop

Control box

Data input

USB memory interface, Ethernet 10/100 base-T network interface

Machine pattern memory

25165824 bits(1024wales*8192addresses)

Control unit

Built-in controller, stored program for flat knitting machine

Control display

Monochrome LCD panel, editing possible via display panel operation, available in Chinese and English

Back-up power

Power supply for resuming knitting after power failure

Power

single phase AC220±10%
about 1.5kw,max 2.5kw
